Mezzanine Floor Pricing

At Oracle mezzanine floors we are able to produce fast, accurate and competitive quotes, using up to date in house CAD drawing facilities along with an accurate production schedule based on actual manufacturing and installation team availability.

We offer to carry out a free site survey of the premises, which we recommend so that the design, cad drawing and quote is accurate to your requirements or, we can work from an architects or a drawing from another. For this option we would also need the following mezzanine floor information.

Mezzanine Floor Site Location: (Town)
Floor length (front to back): (Metres)
Floor width left to right: (Metres)
Finish floor or clear underside height: (Metres)
Handrailing & kickplate Linear: (Metres)
Based on the size of the floor we will be able to work out travel distance for qty of staircases required
Mezzanine Floor Usage?
Storage Mezzanine, Production Mezzanine Flooring, Office Mezzanine, Leisure or Retail Mezzanine floor.

The floor may need to be fire rated, if the mezzanine occupies 50% or more of the ground floor area, if the mezzanine floor is to be used for offices or has people working on it, if the size of the platform is more than 20 metres in either direction, it should be fire protected. Basically a fire protected floor is a suspended fire rated ceiling underneath the mezzanine floor with lighting and emergency exit signs, with facia to the exposed edges of the floor, along with claddling for the mezzanine floor support posts.

Again, we would always recommend allowing us to survey the area in question, but by giving us the information above, we would be able to give you a figure for budget purposes only.

Building Regulations & Planning

Oracle Mezzanine Floors take full responsibility for ensuring that the project is designed in compliance with all current Building Regulations, quality standards and best practice guidance, and for submission of plans to achieve the required consents. We ensure that safety, access and fire regulations are taken into account at the design stage and we even provide higher specification moisture-resistant decking as standard to ensure that our floors remain safe throughout their service life.

Oracle Mezzanine Floors installed in the UK are required to comply with Local Authority Building Regulations in order that the installation can be considered to meet current standards laid down by the relevant Government body - the regulations cover (amongst other things) means of escape in the event of fire, access for disabled users, early warning and protection from fire, etc. The advisor will also cover the implications for your Fire Certification in concert with your local Fire Officer, and help you to comply with this requirement too.

The legislation is contained within the current Building Regulations which can be viewed on the Local Authority Building Control website, however there are various bodies who will help you to understand and identify which standards you must meet for your proposal - you can contact your own local Council and ask for the Building Control Department, or you might wish to pay for an Approved Inspector to advise you (this route may cost you a little more, however it normally results in a speedier response and conclusion). Oracle mezzanine floors use an approved company called Butler & Young who can also fast track the application on our behalf.

Butler & Young Butler & Young Ltd Approved Inspectors has vast experience and expertise of building control for all types of commercial projects. Their expertise has been recognised and has led to strategic alliances with Oracle mezzanine floors, contractors and builders.

WHAT ABOUT PLANNING PERMISSION, IS THIS NEEDED FOR A MEZZANINE FLOOR?
Unless prohibited by a condition attached to a previous consent, planning permission for mezzanine floors is not required as long as the changes are internal. The UK Government has, however, been trying to control the expansion of retail floor space in out-of-town developments and has brought in legislation requiring planning permission for mezzanine floors above 200m². It is permitted, however, to add several mezzanine floors, each just below the 200m² limit without requiring planning consent.

Mezzanine Floor Service

Below is step by step guide to the way Oracle mezzanine Floors delivers your Mezzanine projects. Oracle offers a complete service, from helping with the technicalities of your Mezzanine floor or steelwork enquiry and forming a detailed quotation, right through to installation.

Oracle supply mezzanine floors of all sizes, from 10m² to well over 15,000m², for all kinds of applications, including retail, industrial, commercial offices, warehousing and self-storage.

Oracle’s design capability means we can efficiently produce mezzanine floor projects, with a project manager as point of contact from placement of your order to handover of the installed product.

Step 1: Site survey and quotation

Oracle will carry out a full site survey of the area in question or work from a given drawing, helping with any technicalities you may have and will then send you a formal detailed quotation.

Typically returned within 48hrs.

Step 2: Order Placed and Project Manager Assigned

As soon as you place an order on one of Oracle’s quotations, we assign a dedicated a project manager to your contract; this project manager is your point of contact throughout the whole project, from survey to completion.

Step 3: Site Survey

The project manager’s first responsability is to visit the site to undertake a final detailed site survey and measurements and ascertain the site conditions and customer’s site requirements. At this foundation stage we would co-ordinate with all parties involved to ensure that we cover all aspects of the manufacturing and installation programme.

Step 4: Mezzanine Design

Oracle uses the latest design software conforming to all relevant British Standards to produce a working cad model of your floor along with calculations proving the design.

Step 5: Approval of Mezzanine Design by Customer

Working drawings are issued to the customer for approval. If any changes are required these are made by the project manager to approve the design for the project to proceed. A formal copy of all drawings and calculations to substantiate the design are forwarded for all contracts prior to installation.

Step 6: In House Manufacture and Delivery to Site

Oracle mezzanine’s is proud of its iUK manufacturing capability of mezzanine floors, which enables us to ensure the highest levels of quality and installation programme control whilst offering excellent lead times.

Step 7: Mezzanine Installation

Oracle approves and works with professional installation teams that work to the latest regulations and CDM requirements.

Your assigned project manager stays in close touch with the site manager and installation team to ensure the installation runs smoothly.

Step 8: Customer Satisfaction

Oracle completely checks the site and hands over the defect-free floor to you.

Mezzanine Floor Quality

The standard specification of an Oracle mezzanine floor is unmatched in the industry but, thanks to the accuracy and efficiency of the deisgn, the cost is often more competitive than inferior installations. Each Oracle mezzanine floor includes bespoke design, the latest in lightweight steel structures, high quality powder-coated ancillaries, fully integrated edge protection systems and moisture resistant decking as standard. All mezzanines are designed by Hi-Level and produced to meet BRE Digest 437 requirements and all relevant British Standards resulting in floors that are widely acknowledged to be the ultimate in terms of design, quality and finish.

All Oracle mezzanine floors conform to structural steel code BS 5950: Parts 1 and 5: Structural use of steel building, the general requirements of the Building Regulations and with BRE Digest 437. Ancillaries such as staircases, handrails and toe plates are designed to conform to BS 5395: Parts 1 and 3: Stairs, ladders and walkways and the Building Regulations Part K Stairways, ramps and guards, Design is to suit the loading category of intended use as covered by BS 6399: Part 1: Code of practice for dead and imposed loads

Mezzanine Floor Advantages

  * Cost-efficient increased space
  * Fully demountable, so they can be relocated at a later date
  * Increased potential storage space
  * Avoids relocation costs by making use of available space
  * Flexible design option, can be used for many purposes
  * Excellent fire protection available
  * Lightweight, economic steel structure
  * Bespoke design to meet precise customer requirements
  * Seamless integration within existing environment
  * Fast-track construction, with minimum disruption
  * High quality, powder coated ancillaries in a wide choice of colours
